48 port Multi-Gig 1G/2.5G/5G 90W/30W Suis POE
1/2
  • 48 port Multi-Gig 1G/2.5G/5G 90W/30W Suis POE
  • Get Extreme Networks X450-G2 Series (24p) from Malaysia Distributor - vnetwork
48 port Multi-Gig 1G/2.5G/5G 90W/30W Suis POE

Extreme Networks

48 port Multi-Gig 1G/2.5G/5G 90W/30W Suis POE

SKU: 16173
Pre Order
RM15,423.75

The X450-G2 series is based on Extreme Networks ExtremeXOS, a highly resilient OS that provides continuous uptime, manageability, and operational efficiency. Each switch offers the same high-performance, non-blocking hardware technology, The X450-G2 series switches provide high-performance routing and switching, flexible stacking, PoE+support, and comprehensive security, while extending the benefits of ExtremeXOS to the campus edge.
RM15,423.75
RM463.32
RM15,423.75

Pembaharuan automatik, langkau atau batal pada bila-bila masa. Lihat dasar langganan

Untuk menambah ke troli, pergi ke halaman produk dan pilih opsyen pembelian
What's In the Box
  • 24 x 10/100/1000BASE-T PoE-Plus
  • 4 x 1GBASE-X SFP (unpopulated ports)
  • 2 dedicated QSFP-form factor 21Gbps stacking ports on the rear panel
  • Power Cord, 10A, UK, BS 1363, IEC320-C15
  • Fan Module for Summit X460-G2/X450-G2 Series Switches - front to back airflow
  • Extreme PartnerWorks Plus PWP NBD AHR 16173, 3yr
  • vCare Extreme PW-RPL85NBD X450-G2-24p-10GE4-Base, 3y
Features

Extreme Networks 4220 Suis bertindan berbilang gigabit terurus awan 48-port (740W PoE) dengan port 8x1G/2.5G/ 5GBaseT 90W PoE, 40x10/100/1000BaseT 30W PoE port, 4x1G+10G port. Termasuk Kipas, 1 PSU AC Tetap dengan pilihan untuk menambah PSU berlebihan luaran, Kit Rack-Mount, perisian Base

Datang dengan:
• 8 x 1G/2.5G/5GBaseT 802.3bt (90W) Port PoE
• Port PoE 40 x 10/100/1000Base-T 802.3at (30W)
• 4 x 1/10Gb SFP+ uplink/port susun (tidak berpenghuni)
• 1 x 10/100/1000BASE-T port pengurusan luar jalur
• 1 x Port konsol bersiri (RJ-45)
• 1 x port USB A
• 1 x port konsol USB Micro-B
- 1 x Kabel Penyusun
- Langganan SaaS ExtremeCloud IQ Pilot 1 Tahun
- 1 Tahun Extreme PartnerWorks Plus PWP TAC & PERISIAN 4220-8MW-40P-4X
- 1 Tahun vCare Extreme PW-RPL85NBD 4220-8MW-40P-4X

Lembaran data
Specifications
  • Maximum Active 1Gbe Ports: 24
  • Maximum Active 10Gbe Ports: 4
  • 21 Gbps Stacking Ports: 2
  • Aggregated Switch Bandwidth*: 212 Gbps
  • Frame Forwarding Rate*: 157.7 Mpps
  • Less than 4 microsecond latency (64-byte)
  • Layer 2/MAC Addresses: 68K
  • IPv4 LPM Entries: 16K
  • IPv6 LPM (64-bit) Entries: 8K
  • IPv6 LPM (128-bit) Entries: 256
  • 4096 VLAN/VMANs*
  • 9216 Byte Max Packet Size (Jumbo Frame)
  • 128 load sharing trunks, up to 32 members per trunk
  • 1,024 ingress bandwidth meters
  • Ingress and egress bandwidth policing/rate limiting per flow/ACL
  • 8 QoS egress queues/port
  • Egress bandwidth rate shaping per egress queue and per port
  • Rate Limiting Granularity: 8 Kbps
  • Rate Limiting: Per Class of Service
  • All ports Full Duplex - half duplex operation is not supported

* 2 VLANs reserved for system use

Policy Capabilities

  • Policy Profiles: 63
  • Rules per Profile: Up to 1464
  • Authenticated Policy Users per Switch: Up to 1024
  • Authenticated Policy Users per Port: Up to 1024
  • Unique Permit/Deny Rules per switch: 1464
  • MAC Rules: 512
  • IPv4 Rules: 512
  • IPv6 Rules: 256
  • L2 Rules: 184

Note: Policy and rule limits here reflect support available in EXOS22.1.
Documentations

Datasheet
