48 port Multi-Gig 1G/2.5G 90W POE Switch
1/2
  • 48 port Multi-Gig 1G/2.5G 90W POE Switch
  • 48 port Multi-Gig 1G/2.5G 90W POE Switch
48 port Multi-Gig 1G/2.5G 90W POE Switch

Extreme Networks

48 port Multi-Gig 1G/2.5G 90W POE Switch

SKU: 4120-48MW-4Y
Pre Order
RM29,555.00

Extreme Networks 4120 48-port cloud-managed stackable Multi-Gig switch with 48x10M/100M/1G/2.5GBaseT 90W PoE ports, 2x100G QSFP28 Universal/Stack ports, 4x25G SFP28 ports, fixed fans, 1 internal fixed AC PSU, 1 unpopulated modular PSU slot, Base Software

Request a Quote

Looking for the right solution for your business? Share your requirements with us and our team will prepare a customised quotation tailored to your needs.

Provide as much detail as possible—such as project scope, site location, and timeline—so we can better understand your requirements the most suitable solution. We’ll review your request and get back to you shortly.
What's In the Box
  • Switch
  • Accessories box (2-post rack mount Kit (2 rack ears), rubber feet (4), screws (8))
Features

The front panel of the 4120-48MW-4Y switch includes:

  • 1 = 2 x USB Type-A ports
  • 2 = USB Micro-B console port
  • 3 = System LEDs
  • 4 = Mode button
  • 5 = 4 x 1/10/25Gb SFP28 ports
  • 6 = 2 x 100G Universal/Stacking/QSFP28 ports
  • 7 = 48 x 10M/100M/1G/2.5GBase-T ports
4120-48MW-4Y Front View
4120-48MW-4Y Front View

The rear panel of the switch includes:

  • 1 = Grounding lug
  • 2 = Serial console port (RJ-45)
  • 3 = 100/1000BASE-T OOB management port
  • 4 = 3 x Fan modules
  • 5 = 1 x Internal AC power supply and 1 x replaceable power supply slot
4120-48MW-4Y Rear View
4120-48MW-4Y Rear View
Specifications
  • 48 x 10M/100M/1G/2.5GBase-T ports
  • 4 x 1/10/25Gb SFP28 ports (unpopulated)
  • 2 x Stacking/QSFP28 ports (unpopulated)
  • 1 x 100/1000BASE-T out-of-band management port
  • 1 x Serial console port (RJ-45)
  • 2 x USB A port
  • 1 x USB Micro-B console port
  • 1 x Stacking Cable
  • 1 Year ExtremeCloud IQ Pilot SaaS Subscription
  • 1 Year Extreme PartnerWorks Plus PWP TAC & SOFTWARE 4120-48MW-4Y
  • 1 Year vCare Extreme PW-RPL85NBD 4120-48MW-4Y
