PDU20BHVIEC12R

CyberPower

PDU20BHVIEC12R

SKU: PDU20BHVIEC12R
Pre Order
RM890.00

CyberPower PDU20BHVIEC12R provides output from a UPS unit, generator or utility power to enable multiple connected devices in IT environments. Designed with rugged, industrial-grade metal housing and an ultra-long input power cord, the product supports installation in demanding environments or where only distant power sources are available. The product's capability to work under high temperature allows it to continuously operate reliably and efficiently.
RM890.00
RM890.00

Auto-renews, skip or cancel anytime. View subscription policy

To add to cart, go to the product page and select a purchase option
What's In the Box
  • PDU20BHVIEC12R
  • User's Manual
  • Product Registration Card
  • Cord Retention Tray
  • Mounting Brackets
  • Cable Ties
  • Screw Kit
  • Power Cord

* Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide.
Features
  • Overload Protection
  • Industrial-grade Metal Housing
  • Cord Retention Tray
  • Work under High Temperature
  • Adjustable Mounting Brackets
  • IEC Receptacle Locking
Specifications

GENERAL

  • Type: Basic
  • Phase: Single Phase


INPUT

  • Nominal Input Voltage(Vac): 200 ~ 240
  • Input Frequency(Hz)50 / 60
  • Maximum Input Current(A): 16(UL); 16(CE)
  • Input Connector Type: IEC C20x1
  • Power Cord Length (ft.): 10
  • Power Cord Length (m.)3.05


OUTPUT

  • Output Voltage(V): Depends on Input
  • Overload Protection: Circuit Breaker
  • Over Current Protection (Each Bank)(A): 20
  • Outlet(s) - Total: 12
  • Outlet(s) - Rear: 12
  • Outlet Type: IEC C13x12


PHYSICAL

  • Installed Rack Height (U): 1
  • Form Factor: 1U Vertical Rackmount, 1U Horizontal Rackmount, Undercounter Installation Supported
  • Enclosure Construction: Steel
  • Color: Black
  • Cord Retention Tray: Yes
  • IEC Receptacle Locking: Yes
  • External Site Ground Pin: Yes
  • Adjustable Mounting Brackets: 2 Set (L-short, L-long)


PHYSICAL SIZE

  • Dimensions (WxHxD) (in.): 17.5 x 1.75 x 1.5
  • Dimensions (WxHxD) (mm.): 445 x 44.5 x 38.1
  • Weight (lbs.): 4.41
  • Weight (kg.): 2


SHIPPING DIMENSIONS

  • Dimensions (WxHxD) (in.): 20.9 x 9.1 x 13.0
  • Dimensions (WxHxD) (mm.): 530 x 233 x 330
  • Weight (lbs.): 32.76
  • Weight (kg.): 14.86


ENVIRONMENTAL

  • High Temperature Operation: Yes
  • Operating Temperature (°F): 32 ~ 122
  • Operating Temperature (°C)0 ~ 50
  • Operating Relative Humidity (Non-condensing)(%): 0 ~ 95
  • Operating Elevation(feet/meters): 0-13,123 feet (0-4,000 meters)
  • Storage Temperature (°F): 5 ~ 131
  • Storage Temperature (°C): -15 ~ 55
  • Storage Relative Humidity (Non-condensing)(%): 0 ~ 95
  • Storage Elevation(feet/meters): 0-49,213 feet (0-15,000 meters)


CERTIFICATIONS

  • Certifications: CE, UL60950, UL62368RoHSYes


WARRANTY

  • Product Warranty Period(Year): 2
Documentations

User's Manual

Declaration of Conformity

Image Disclaimer:

Product images are for illustrative purposes only. Actual product colors, textures, sizes, and details may vary due to lighting, screen settings, or production changes. Please refer to the product description for accurate specifications.
