X440-G2-12t-10GE4
1/4
  • X440-G2-12t-10GE4
  • X440-G2-12t-10GE4
  • X440-G2-12t-10GE4
  • X440-G2-12t-10GE4
X440-G2-12t-10GE4

Extreme Networks

X440-G2-12t-10GE4

SKU: 16540
Pre Order
RM10,676.25

The ExtremeSwitching X440-G2 series is a scalable cost-effective family of edge switches powered by Extreme Networks ExtremeXOS, a highly resilient OS providing continuous uptime, manageability and operational efficiency. The X440-G2 series switches provide high-performance routing and switching, flexible stacking, PoE+ support and comprehensive security, while extending the benefits of ExtremeXOS to the campus edge.
RM10,676.25
RM320.76
RM10,676.25

Auto-renews, skip or cancel anytime. View subscription policy

To add to cart, go to the product page and select a purchase option
What's In the Box
  • Power Cord, 10A, UK, BS 1363, IEC320-C15
  • Extreme PartnerWorks Plus NBD AHR 16540, 3yr
  • vCare Extreme PW-RPL85NBD X440-G2-12t8fx-GE4, 3y
Features
  • Scalable cost-effective edge switches
  • 12, 24, and 48-port Gigabit Ethernet connectivity
  • 4 x 1Gb uplinks upgradeable to 10Gb via software license
  • PoE/PoE+ models for powered connection of edge devices
  • SFP and 100Base-FX fiber model options
  • AC and DC Power options
  • Non-blocking, wire-speed design
  • Up to 8-unit 40Gb stacking via SummitStack-V
  • Role-based policy and Fabric Attach for secure, automated access to network applications or services



Smart Management Choices

  • ExtremeCloud™ IQ for powerful, simple and secure public or private cloud management
  • Extreme Management Centerfor centralized, unified management capabilities
  • Extreme Cloud Appliance for campus or private cloud requirements
Specifications
  • Maximum 10/100/1000 Base-T Ports: 12
  • Maximum Active 1Gb SFP Ports: 4
  • Maximum 10Gb SFP+ Ports: 4 via license
  • Aggregated Switch Bandwidth*: 104 GBPS
  • Frame Forwarding Rate*: 77.4 MPPS

2 10GBase-T combo ports
*with 10Gb licenses if available with license

  • Less than 4 microsecond latency (64-byte)
  • Layer 2/MAC Addresses: 16K
  • IPv4 LPM Entries: 480
  • IPv4 Hosts: 100
  • IPv6 LPM (64-bit) Entries: 240
  • 4096 user-created VLAN/VMANs *
  • 9216 Byte Max Packet Size (Jumbo Frame)
  • 128 load sharing trunks, up to 8 members per trunk
  • 1,024 ingress bandwidth meters, 256 egress meters
  • Ingress and egress bandwidth policing/rate limiting per flow/ACL
  • 8 QoS egress queues/port
  • Egress bandwidth rate shaping per egress queue and per port.
  • Rate Limiting Granularity: 8 Kbps
  • Half-duplex 10/100 supported on the following 10/100/1000 ports:
  • 12 port switches: Ports 1-12
  • 24 port switches: Ports 1-16
  • 48 port switches: Ports 1-16 and Ports 25-40

* 2 VLANs reserved for system use

  • LRM support on rear-panel SFP/SFP+ ports on all 48-port switches

Policy Capabilities

  • Policy Profiles: 63
  • Rules per Profile: Up to 440
  • Authenticated Policy Users per Switch: Up to 1,536
  • Authenticated Policy Users per Port: Up to 1,536
  • Unique Permit/Deny Rules per switch: 440
  • MAC Rules: N/A
  • IPv4 Rules: 256
  • IPv6 Rules: N/A
  • L2 Rules: 184
  • Rate Limiting: Per Class of Service
Documentations

Datasheet
