Get Extreme Networks X460-G2 Series (24p) from Malaysia Distributor - vnetwork
  • Get Extreme Networks X460-G2 Series (24p) from Malaysia Distributor - vnetwork
X460-G2-24p-10GE4

Extreme Networks

X460-G2-24p-10GE4

SKU: 16756
Pre Order
RM19,718.75

The X460-G2 series is based on Extreme Networks revolutionary ExtremeXOS, a highly resilient OS that provides continuous uptime, manageability and operational efficiency. Each switch offers the same high- performance, non-blocking hardware technology, in the Extreme Networks tradition of simplifying network deployments through the use of common hardware and software throughout the network.
RM19,718.75
RM591.84
RM19,718.75

Auto-renews, skip or cancel anytime. View subscription policy

To add to cart, go to the product page and select a purchase option
What's In the Box
  • 24 x 10/100/1000BASE-T Full-Duplex PoE-Plus
  • 24 x 10/100/1000BASE-T Full/Half-Duplex PoE-Plus
  • 4 x 10GBASE-X SFP+ (unpopulated ports)
  • Power Cord, 10A, UK, BS 1363, IEC320-C15
  • Fan Module for Summit X460-G2/X450-G2 Series Switches - front to back airflow
  • Extreme PartnerWoarks Plus PWP NBD AHR 16756, 3yr
  • vCare Extreme PW-RPL85NBD X460-G2-24t-24ht-10GE4-Base, 3y
Features

    Performance

    • 48-port or 28-port GbE models
    • 4 ports of SFP+ 10GbE or 4 ports of SFP 1GbE on front faceplate
    • 16 port multi-rate (100Mb/1/2.5Gb) PoE+ switch with 32 10/100/1000 PoE+ ports
    • All configurations Non-blocking full duplex
    • Two new 48 port switches with 10GbE uplinks that support 24 ports with half/full-duplex operation
    • Copper, Fiber, and PoE-Plus models
    • Optional two-port 10 GbE fiber and copper options to provide additional 10Gbps streams of uplink bandwidth
    • Optional two-port 40 GbE to provide 80 Gbps uplinks or SummitStack-V160 stacking
    • 40 Gbps stacking via front-panel 10Gb Ethernet ports or optional SummitStack

    Form Factor

    • 1 RU w/ 1 expansion slot for additional interface ports and 1 expansion slot for timing options

    Features

    • Secure Network Access through role based policy or Identity Management
    • Front-to-Back or Back-to-Front airflow
    • SyncE G.8232 and IEEE 1588 PTP Timing
    • 850W of PoE-Plus budget with 1 PSU
    • 1440W of PoE-Plus budget with 2 PSUs
    • Multi-rate Ethernet (100Mb/1/2.5Gb) support
    • Y.1731 OAM Measurements in hardware for accuracy
    • Energy Efficient Ethernet – IEEE 802.3az on 10/100/1000 ports
    • Hot-Swappable Power Supplies and Fan Tray



    T&C (Terms and condition):

    • 3-Year Network-as-a-Service (NaaS) Subscription Package
    • Inclusive of Installation, Support Services, Management, Monitoring and Reporting.
    • Valid for standard configuration and installation within the Klang Valley. For outstation services or custom configurations, please contact us directly.
    • Promotion valid till 27 June 2025 or While stock last
    Specifications
    • Maximum Active 10/100/1000MbE Ports: 28
    • Maximum Active 100MbE/1/2.5GbE Ports: -
    • Maximum Active 10GbE Ports: 6
    • Maximum Active 40GbE Ports: 2
    • Aggregated Switch Bandwidth*: 296Gbps
    • Frame Forwarding Rate*: 220.2Mpps
    • Less than 4 microsecond latency (64-byte)
    • Layer 2/MAC Addresses: 96K (98,304)
    • IPv4 Host Addresses: 62K
    • IPv4 LPM Entries: 12K, 16K on X460-G2-16mp-32p-10GE4
    • IPv6 Host Addresses: 24K
    • IPv6 LPM Entries: 6K, 8K on X460-G2-16mp-32p-10GE4
    • 4096 VLAN/VMANs
    • 9216 Byte Max Packet Size (Jumbo Frame)
    • 128 load sharing trunks, up to 32 members per trunk
    • 4,096 ingress bandwidth meters
    • Ingress and egress bandwidth policing/rate limiting per flow/ACL
    • 8 QoS egress queues/port
    • Egress bandwidth rate shaping per egress queue and per port
    • Rate Limiting Granularity: 8 Kbps
    • All ports Full Duplex - half duplex operation is not
    • supported except for 24 ports on X460-G2-24p-24hp-
    • 10GE4 and X460-G2-24t-24ht-10GE4
    • Policy Capabilities: Rules per Profile: Up to 1464; Authenticated Policy Users per Switch: Up to 12,288; Authenticated Policy Users per Port: Up to 12,288
    • Unique Permit/Deny Rules per switch: 1464
    • The following number of rules listed below can be affected by the switch configuration options in EXOS 22.4 or greater
    • MAC Rules: up to 512
    • IPv4 Rules: up to 1280
    • IPv6 Rules: up to 256
    • L2 Rules: up to 184
    • Rate Limiting: Per Class of Service
    • NOTE: Policy and rule limits here reflect support available in EXOS 22.4 or greater
    Documentations

    Datasheet

    Quick Reference Guide
